光波通信实验室

365体育平台自2011 年初成立以来，已经购置了包括56 Gb/s误码测试系统（另包含4 路独立28 Gb/s 信号输出）、100 Gsa/s 实时示波器系统（4 通道33 GHz 模拟带宽输入）、窄线宽可调激光器系统（配备2 个可调激光器）、80 GHz 采样示波器、75 GHz 频谱仪、67 GHz 矢量网络分析仪、67 GHz 模拟信号源、可升级带宽的24 Gsa/s 任意信号发生器（AWG）、超短脉冲激光器、高精度光谱仪、光纤环路系统、光相干接收机、高性能计算服务器等设备，以及相干光通信系统相关的光IQ 调制器、超线性微波放大器、光放大器、各种光纤等器件。实验设备具体如下：

信号产生：

[1] 67 GHz 模拟信号源，Agilent E8257D

http://www.home.agilent.com/en/pd-460865-pn-E8257D/psg-analog-signal-generator?&cc=CN&lc=chi

[2] 24 Gsa/s 任意信号发生器，Tektronix AWG7122C

http://www.tek.com/signal-generator/awg7000-arbitrary-waveform-generator

[3] 56 Gb/s 误码测试系统，Anritsu MP1800A + MP1821A

http://www.anritsu.com/en-US/Downloads/Brochures-Datasheets-and-Catalogs/Brochure/DWL8401.aspx

 [4] 67 GHz 矢量网络分析仪，Agilent N5247A

[5] 外腔可调激光器，Agilent 81600B；Agilent 81980A

http://www.home.agilent.com/en/pd-74026-pn-8164B/lightwave-measurement-system?&cc=HK&lc=eng

信号调制：
[6] 微波放大器：SHF 807（33 GHz）；Centellax OA4MVM3 （40 GHz）

http://www.shf.de/communication/products/rf_broadband_amplifier/ultra_linear_rf_amplifier/

http://www.centellax.com/products/telecom/modules/OA4MVM3.shtml

[7] 电光调制器：Fujitsu FTM7961（IQ调制器）；Fujitsu FTM7938 （40 Gb/s）


http://jp.fujitsu.com/group/foc/en/services/optical-devices/40gln/

[8] 掺铒光纤放大器：Amonics AEDFA-CL-17；Amonics AEDFA-PA-30

http://www.amonics.com/amonics/php/en/products_details.php?id=29

[9] 混频器：CMB43431009H；Agilent 11970V


http://www.cernex.com/PRODUCTS_NEW/Mixer-PDF/Balance%20Mixers.pdf

http://www.home.agilent.com/en/pd-1000001193%3Aepsg%3Apro-pn-11970V/waveguide-harmonic-mixer-50-to-75-ghz?nid=-33401.536879175&cc=HK&lc=eng

[10] 光电探测器：u2t XPDV3120R（75 GHz）；u2t BPDV2125


http://www.u2t.com/products/photodetectors/item/bpdv2xx0r?category_id=2
http://www.u2t.com/products/photodetectors/item/xpdv21x0ra?category_id=2

[11] 光环路系统

http://www.brimrose.com/products/fiber_optics/recirculating_loop_system.html

信号分析：
[12]  33 GHz实时示波器：Tektronix DSO73304D

http://www.tek.com/oscilloscope/dpo70000-dsa70000-mso70000

[13]  80 GHz宽带示波器（眼图仪）：Agilent 86100D


http://www.home.agilent.com/en/pd-1846742-pn-86100D/infiniium-dca-x-wide-bandwidth-oscilloscope-mainframe?&cc=HK&lc=eng

[14]  75 GHz 频谱仪：Agilent N9030A

http://www.home.agilent.com/en/pd-1721037-pn-N9030A/pxa-signal-analyzer?&cc=HK&lc=eng

[15]  5MHz分辨率光谱仪：APEX 2040A

http://www.apex-t.com/apex_instruments.htm

[16]  0.02 nm 光谱分析仪（600 nm – 1700 nm）：Yokogawa AQ6370C

http://tmi.yokogawa.com/products/optical-measuring-instruments/optical-spectrum-analyzer/aq6370c-optical-spectrum-analyzer/

[17] 1200 nm – 2400 nm 光谱仪Yokogawa AQ6375C


http://tmi.yokogawa.com/products/optical-measuring-instruments/optical-spectrum-analyzer/aq6375-optical-spectrum-analyzer/
